iDEAL TP10KAC-DX 10,000 LB. ALI CERTIFIED 2-POST BI-SYMMETRIC CLEAR FLOOR LIFT Lift - Two Post iDEAL Freedom Shop Equipment iDEAL TP10KAC-DX 10,000 LB. ALI CERTIFIED 2-POST BI-SYMMETRIC CLEAR FLOOR LIFT

iDEAL TP10KAC-DX 10,000 LB. ALI CERTIFIED 2-POST BI-SYMMETRIC CLEAR FLOOR LIFT

by iDEAL
SKU TP10KAC-DX
$4,249.00 USD - $4,249.00 USD
$4,249.00 USD
$4,249.00 USD - $4,249.00 USD
$4,249.00 USD

iDEAL TP10KAC-DX 10,000 LB. ALI CERTIFIED 2-POST BI-SYMMETRIC CLEAR FLOOR LIFT

The iDEAL TP10KAC-DX 10,000 lbs. ALI Certified two post car lift is a premium Bi-Symmetric design clear floor vehicle lift. Offset three stage short arms and a low pad height of 4” make this lift perfect for a wide range of vehicles. Our rigid single piece column and direct pull cylinder combined with single point lock release and clean design make this lift one of our most popular models.

Promos
Features & Benefits
  • ALI certified
  • 10,000 lbs capacity
  • Bi-Symmetric arm design
  • Rubber Door Guards
  • 3 Stage Front Arms
  • Single Piece Column
  • Direct Drive pull Cylinders
  • Single Point Lock Release
  • Heavy Duty Arm Restraint System
  • Spin Up Low Profile Lift Pads
  • Stackable Adapters Included
  • External hose guards
  • Duro Certifed Power Unit – MET, UL, CSA
Specifications

 Model Number TP10KAC-DX
Lifting Capacity 10,000 lbs.
Height Overall
 144"
Width Overall w/ Power Unit 145-1/2"
Max Lifting Height 71"
Width Between Columns 116"
Min Pad Height 4"
Drive-Thru Clearance 104"
Lifting Speed 50s
Asymmetric / Symmetric Bi-Symmetric
Clear Floor / Floor Plate Clear Floor
Short Arm Reach - Min. / Max. 23" - 45"
Long Arm Reach - Min. / Max. 41" - 59"
Narrow Bay Setting N/A
Max Load Per Arm 2,500 lbs.
Ceiling Height Required 145"
Power 220v-20amp,1Ph
Ship Weight 1,705 lbs.

Brochures

Download TP10KAC-DX Brochure

Download TP10KAC-DX Manual

Warranty

1 year Parts, 5 years Structural
